Olympus Nortec 600D Eddy Current Flaw Detector

Olympus Nortec 600D Eddy Current Flaw Detector

The Olympus Nortec 600D Eddy Current Flaw Detector is a portable, high-performance instrument used for non-destructive testing (NDT) to detect surface and near-surface defects in conductive materials. It uses the principles of eddy current testing (ECT), which involves inducing electric currents (eddy currents) into a test material and measuring their response to identify flaws such as cracks, corrosion, or coatings thickness.

Features:

1. Portable and Rugged Design: The 600D is designed for field use, offering portability and durability, making it suitable for harsh industrial environments.
2. Advanced Signal Processing: It provides high-resolution data, allowing for precise detection of defects in conductive materials.
3. Multiple Probe Compatibility: The instrument supports a wide range of probes and accessories, enabling users to tailor their testing to various applications.
4. High Sensitivity: Its sensitivity to small changes in material properties allows it to detect subtle flaws.
5. Versatile Applications: It can be used for a variety of applications, such as crack detection, coating thickness measurement, and corrosion monitoring in aerospace, automotive, and industrial settings.
6. Clear Display: The detector typically features a clear, easy-to-read display that helps users interpret data quickly, even in challenging environments.
7. User-Friendly Interface: With a straightforward, intuitive interface, it allows operators to set up and perform tests with minimal training.

Typical Applications:

• Aerospace: Inspection of aircraft fuselages and wings for cracks or corrosion.
• Power Generation: Monitoring turbine blades and other critical components for fatigue or wear.
• Oil & Gas: Inspection of pipelines and equipment for corrosion or material degradation.
• Automotive: Checking automotive parts like wheels and suspension components for defects.

Advantages:

• Non-contact Testing: No need for direct contact with the material surface, which is ideal for delicate or hard-to-reach areas.
• Real-time Results: Provides immediate feedback, which can be crucial for decision-making during inspections.
• Minimal Preparation: Requires minimal setup time and calibration, making it efficient for on-site inspections.

General Specifications:

• Display:
  • 5.7-inch color LCD display (320 x 240 resolution)
  • Adjustable backlight for improved visibility in various lighting conditions
• Power Supply:
  • Rechargeable lithium-ion battery
  • Battery life: Typically up to 8 hours of continuous operation (depending on usage and settings)
• Dimensions:
  • 10.6 x 7.3 x 3.5 inches (270 x 185 x 90 mm)
• Weight:
  • Approximately 2.7 lbs (1.2 kg)
• Environmental Protection:
  • IP54 rating, providing protection against dust and water splashes
  • Operating temperature range: -10°C to +50°C (14°F to 122°F)
  • Storage temperature range: -20°C to +60°C (-4°F to 140°F)

Eddy Current Testing Features:

• Frequency Range:
  • 10 Hz to 12 MHz (depending on probe and application)
• Signal Processing:
  • Advanced signal filtering for enhanced sensitivity and noise reduction
  • Display modes: A-scan, B-scan, and phase analysis (depending on configuration)
• Impedance Plane (Lissajous) Display: Provides phase and amplitude data for comprehensive analysis
• Sensitivity:
  • High sensitivity for small defects, such as cracks or pits, in conductive materials
  • Capable of measuring very fine variations in the material’s electrical conductivity

Probes and Accessories Compatibility:

• Supports a wide range of probes, including:
  • Standard surface probes (single coil, differential)
  • Reflection probes
  • Array probes (for more advanced inspections)
  • Pencil probes
• Probe Frequency Range: Typically from 10 Hz to several MHz, depending on the probe type used
• Probes and Accessories: Interchangeable with other Olympus eddy current accessories

Software and Data Storage:

• Memory:
  • Internal storage to save test data and results
  • Data transfer via USB port (for storing reports or further analysis)
  • Can be integrated with PC software for advanced analysis and reporting
• Software: The detector may be used with Olympus’s software tools for more detailed analysis and reporting, such as the OmniScan® software for multi-channel eddy current inspections.

Calibration and Setup:

• Automated Calibration: The unit can auto-calibrate or manually calibrate for specific material and probe conditions
• Customization: Users can set up inspection parameters like gain, frequency, and impedance threshold for different inspection tasks.

Additional Features:

• Data Logging: The device can log inspection results with date/time stamps for documentation and traceability.
• Multi-Language Support: The interface supports multiple languages for ease of use in different regions.
• Built-in Help System: Provides on-screen help for easier setup and troubleshooting.

Applications and Uses:

• Aerospace: Aircraft components such as fuselage, wings, and landing gear inspection
• Automotive: Detection of cracks or corrosion in components like wheels, suspension, and exhaust systems
• Oil & Gas: Pipeline and equipment inspection for corrosion or material degradation
• Power Generation: Turbine blades and other critical components inspection for fatigue

– Long battery life up to 10 hours
– Engineered to meet IP66 requirements
– 10 Hz to 12 MHz frequency capacity
– Stores up to 500 files (program and data)
– EN-15548 compliant
– Bright, 5.7-inch (14.5 cm) VGA display
– Improved filters for rotary scanner mode
– Full-screen option in any display mode
– Intuitive interface with application selection presets
– Automatic internal balancing (BNC connector)
– All-settings configuration page
– Up to two real-time readings
– True automatic mixing
– On-board file preview
